375nm 25mm Dia., High Performance Longpass Filter

High Performance OD 4.0 Longpass Filters

×
Stock #34-302
- +
C$364.00
Qty 1-5
C$364.00
Qty 6+
C$312.20
Volume Pricing
Request Quote
×
Get Product Downloads
Diameter (mm):
25.00 +0/-0.2
Angle of Incidence (°):
0
Optical Density OD (Average):
≥4.0
Cut-On Wavelength (nm):
375.00
Substrate: Many glass manufacturers offer the same material characteristics under different trade names. Learn More
Fused Silica (Corning 7980)
Coating:
Hard Coated
Rejection Wavelength (nm):
200 - 365
Surface Quality:
60-40
Thickness (mm):
1.50
Thickness Tolerance (mm):
±0.1
Transmission (%):
>91
Transmission Wavelength (nm):
383 - 1600
Type:
Longpass Filter
Clear Aperture (%):
>80
Durability:
MIL-C-48497A, Section 3.4.1
Transmitted Wavefront, RMS:
≤λ/4 @ 633nm
Cut-On Tolerance (%):
±1
Slope Factor (%):
1.00
Coating Specification:
Surface 1: Hard Dielectric Sputtered
Surface 2: AR Coated
Wavelength Range (nm):
200 - 1600

Regulatory Compliance

RoHS 2015:
Compliant
×
Reach 224:
Compliant
×
Certificate of Conformance:
View
×

Product Family Description

Our High Performance Longpass filters feature high transmission in the pass band combined with superior blocking in the rejection band. With a rejection band optical density of 4.0 combined with >91% in the pass band these filters are ideal for a wide variety of applications. Eliminate stray light by creating custom bandpass filters when combined with our TECHSPEC® High Performance Shortpass Filters.

Note: These filters are optimized for high spectral performance rather than high Laser Induced Damage Thresholds (LIDT). A typical LIDT for these filters is 1 J/cm2 @ 532nm, 10ns. Please contact us if you require a filter with a higher LIDT value.

Our TECHSPEC® Rotating Filter Wheel can be used for applications requiring a variety of filters.
